Building on the original award-winning DC7, this updated V2 model runs more efficiently and cooler, while the upgraded USB-C output now delivers three times more power for phones, tablets and USB-C devices. Whether you are running a compact grab-and-go board or a deep, MIDI-controlled setup, DC7 V2 gives you rock-solid, noise-free performance in a chassis that is only one inch thick.

Each of the seven isolated outlets offers four selectable voltages, so you can tailor the supply to each pedal without extra adapters or bricks. A clear LED monitoring system keeps you informed about load and headroom at a glance, while the universal mains input makes the DC7 V2 ready for stages and studios around the world.

With included Flex cables and built-in 24 V expansion, DC7 V2 is ready to grow with your rig. Add CIOKS 4, CIOKS 8, Crux or other compatible 24 V units to unlock even more isolated outputs, all while keeping your board neat, quiet and dependable.

Ultra-slim, pedalboard-friendly design

Thanks to CIOKS’ pure 2-stage switch-mode technology, the DC7 V2 has a ground-breaking one-inch (25.4 mm) profile and weighs only 500 g. That makes it easy to mount under most popular pedalboards without sacrificing space on top, while still delivering serious power for demanding setups.

High-current, multi-voltage isolated outputs

Seven fully isolated DC outlets each provide up to 660 mA at 9 V, with selectable 9, 12, 15 or 18 V settings. This lets you power everything from vintage-style drives to current-hungry digital units like amp modellers and multi-effects, all from a single, clean and quiet power source.

Powerful USB-C and 24 V expansion

The upgraded 5 V USB-C output delivers up to 3 A (15 W), ideal for charging phones and tablets or powering USB-C hubs and controllers used in modern rigs. The dedicated 24 V DC auxiliary outlet (2 A) lets you expand easily with CIOKS 4, CIOKS 8, Crux or other compatible 24 V units for even more isolated outputs.

Comprehensive monitoring and included Flex cables

Individual power limit LEDs on every outlet, plus a total load meter and global overload indicators, give you instant visual feedback on how your PSU is performing. With twelve assorted CIOKS Flex cables in the box, you can connect a wide variety of pedals straight away, including centre-negative, centre-positive, 3.5 mm and multi-pedal daisy chain setups.

FEATURES

• Seven high-current isolated outputs - Each outlet can supply up to 660 mA at 9 V, with selectable 9, 12, 15 or 18 V settings, giving you the flexibility to power everything from standard stompboxes to power-hungry digital processors without noise or sag.
• Upgraded 5 V USB-C output - A dedicated USB-C outlet provides up to 3 A (15 W), making it perfect for charging mobile devices or powering USB-C accessories such as controllers and hubs that are increasingly common on modern pedalboards.
• 24 V expansion-ready design - The 24 V DC auxiliary output (2 A) allows seamless expansion with CIOKS 4, CIOKS 8, Crux and other compatible 24 V units, so your power system can grow alongside your pedal collection while staying tidy and reliable.
• Ultra-slim, lightweight and globally compatible - With its one-inch profile, 500 g weight and universal 90 to 265 V AC mains input, the DC7 V2 mounts easily under popular boards, travels light and works reliably in venues and studios around the world.

SPECIFICATIONS

General

• Product: CIOKS DC7 V2 Isolated Pedal Power Supply
• Total Maximum Output Power: 48 W
• Technology: 2-stage switch-mode power supply topology
• Noise Reduction: Multi-stage filtering, ultra-low noise design
• Profile Height: 1 inch / 25.4 mm
• Weight: 500 g
• Mains Input Voltage: 90 to 265 V AC (universal)
• Warranty: 5-year worldwide warranty
• Design: Designed in Denmark, assembled in Poland

DC Outputs 1-7

• Number of DC Outputs: 7 isolated outlets
• Each Outlet (9 V): 9 V DC / 660 mA
• Each Outlet (12 V): 12 V DC / 500 mA
• Each Outlet (15 V): 15 V DC / 400 mA
• Each Outlet (18 V): 18 V DC / 330 mA
• Voltage Selection: Independently selectable 9, 12, 15 or 18 V per outlet
• Isolation: Fully isolated DC outputs

Additional Outputs

• USB-C Output: 5 V DC / up to 3 A (15 W)
• Auxiliary Output: 24 V DC / 2 A (for expansion units and compatible 24 V devices)

Monitoring and Indicators

• Per-Outlet Indicators: Individual power limit LEDs on all outputs
• Global Monitoring: Total load meter
• Status Indicators: Global overload status LEDs

Included Cables

• 7 x Standard Flex type 1 (black, 5.5/2.1 mm centre negative DC plug)
• 1 x Standard Flex type 2 (red, 5.5/2.1 mm centre positive DC plug)
• 1 x Standard Flex type 4 (green, 5.5/2.5 mm centre positive DC plug)
• 1 x Standard Flex type 5 (black, tip positive 3.5 mm jack plug)
• 1 x Split Flex type 1 (powers two pedals from a single outlet)
• 1 x 3-way Daisy Chain Flex type 1 (powers three pedals from a single outlet)
• Total Flex Cables Included: 12

Mounting and Compatibility

• Included Mounting Hardware: For Pedaltrain and Templeaudio boards
• Additional Mounting Compatibility: Compatible with CIOKS GRIP for drill-free mounting on Pedaltrain boards
• Expansion Compatibility: CIOKS 4, CIOKS 8, Crux and other compatible 24 V DC-powered units

‍
